RS-232 Standard Factory Settings Enter/Exit Programming Mode
Product Reference Guide
19
RS-232 ONLY Interface
Use the programming bar codes in this chapter if modifications to the standard RS-232
interface settings are necessary to meet your system’s requirements. Additional settings
which apply to both the RS-232 and USB interfaces are available in
Chapter 5, RS-232/USB-
COM Interfaces
.
RS-232 Standard Factory Settings
Reference Appendix B, Standard Defaults for a listing of standard factory settings.
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the scanner's baud rate to
match the baud rate setting of the host device. With an improper baud rate setting, data may
not reach the host correctly.
Baud Rate = 1200
Baud Rate = 2400
Baud Rate = 4800
Baud Rate = 9600
$CR2BA00
$CR2BA01
$CR2BA02
$CR2BA03
