Datalogic DS8110 User Manual

E-GENIUS
93
4
Field Name
Action/Definition
Example 4
Code label setting#1 = Code 93
Code label setting#2 = Interleaved 2/5
Code label setting#3= EAN-8
Code label setting#4= UPC-A
Logical Combination Rule = 1^2&3^4
Defines 2 groups, each of them expecting one of the defined code types. The
first group may expect a Code 93 label or an Interleaved 2/5 label. The second
group may expect an EAN-8 label or an UPC-A label.
Decoded Code
Symbology
Output Message
Label
#1
Label
#2
Label
#3
Label
#4
---
---
---
---
<Header><Global No Read
Message><Terminator>
X
---
---
---
<Header><Global No Read
Message><Terminator>
---
X
---
---
<Header><Global No Read
Message><Terminator>
---
---
X
---
<Header><Global No Read
Message><Terminator>
---
---
---
X
<Header><Global No Read
Message><Terminator>
X
X
---
---
<Header><Global No Read
Message><Terminator>
X
---
X
X
<Header><Code93><DPS>< First decoded
code/Multiple Read Message
string><Terminator>
X
X
X
---
<Header><First decoded code/Multiple Read
Message string><DPS><EAN 8
data><Terminator>
---
X
X
X
<Header>< Interleaved 2/5 data><DPS>< First
decoded code/Multiple Read Message string
><Terminator>
X
---
X
---
<Header><Code 93 data><DPS><EAN 8
data><Terminator>
X
---
---
X
<Header><Code 93 data><DPS><UPC-A
data><Terminator>
---
X
X
---
<Header><Interleaved 2/5 data><DPS><EAN 8
data><Terminator>
---
X
---
X
<Header><Interleaved 2/5 data><DPS><UPC-A
data><Terminator>
X
X
X
X
<Header><First decoded code/Multiple Read
Message string><DPS>< First decoded
code/Multiple Read Message string
><Terminator>
