DS8110 REFERENCE MANUAL
14
2
2.3 INSTALLATION SEQUENCE
To complete mechanical installation and setup, you must:
 Review the details of your application’s requirements
 Erect mounting structure or other supporting structures
 Determine and mark the Mounting Bracket location(s)
 Mount the bracket to the mounting structure
 Mount the DS8110 to its mounting bracket
 Mount the photoelectric sensor to the mounting structure (optional)
 Mount the tachometer to the mounting structure (optional)
 Mount the CBX connection box to the mounting structure
 Mount the SC5000 to the mounting structure
 Complete electrical installation (See Chapter 3)
 Align the DS8110 for proper operation
 Configure the DS8110 (See Chapter 4)
 Check DS8110 operations (See Chapter 5)
NOTE: Everything should be MECHANICALLY INSTALLED before performing
any ELECTRICAL INSTALLATION.
See Chapter 3 Electrical Installation for electrical installation details.
