ELECTRICAL INST
ALLATION
41
3
3.12.2
Encoder/Tachometer Wiring
for PNP Output (tw
o models)
Figure
36
: OEK-2 (93ACC1770) En
coder/Tachometer Wiring (PNP Output)
NOTE:
Som
e tachometers m
ay
have a different col
or coding:
Red (+V)
or
White/Orang
e
White (signal)
or
White/Blue
Black (ground)
or
Orange/Whit
e
52
