Datalogic DS8110 User Manual

ELECTRICAL INSTALLATION
31
3
3.6 CONNECTING A PC TO THE DS8110
During initial setup, a PC (laptop) may be connected to the DS8110 with a M12 to RJ45
cable. Screw the M12 connector to the ETH 2 port of the scanner and plug the RJ45 into the
Ethernet port of your PC. If the ETH 2 port is in use, ETH 1 port can be used. For information
on connecting to e-Genius, see Chapter 4.
NOTE: ETH2 is the Setup port, ETH1 is the HOST port.
NOTE: A laptop can only communicate to a scanner that is connected to a CBX
Connection Box or SC5000 Controller.
NOTE: Parameters for tunnel are set up in MASTER scanner (or SC5000
Controller) only.
