Modify Settings | Global Settings | Ethernet | User Sockets
Use the User Sockets (User Socket Settings) window to setup, edit, and configure
numbered user sockets for your barcode scanning system. User sockets are another
interface available for the Ethernet communication.
To edit the User Socket settings:
1. In the tree menu under Modify Settings, navigate to Global Settings | Ethernet | User
Sockets. The User Sockets window opens.
2. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
User Socket
List
Select an option button in the list at the top of this window to create a new user socket,
or to edit an existing one.
USER SOCKET N
Enable User
Socket
Select the check box to enable User Sockets and reveal the related configuration
options.
Enable Data
Transmission
Select the check box to enable User Sockets and reveal the related configuration
options. When enabled, Ethernet User Socket is selected as the channel to be used
by the scanner for transmitting data and/or messages.
