Select Disable, Enable Unconditioned, or Enable Conditioned from the drop-down
list. This parameter is available when the Data TX parameter is checked. It
enables/disables the transmission of the Heartbeat message signaling that the device
is still active.
Disable: The Heartbeat message is not transmitted
Enable Unconditioned: The Heartbeat message is always transmitted, even if
communication is still active
Enable Conditioned: The Heartbeat message is transmitted only when there is no
communication
Enter a time value in seconds to define the amount of time between two message
transmissions. If the input timeout expires and no transmission has occurred, the
Heartbeat message will be transmitted.
Heartbeat
Message
(max. 32
chars)
Click to activate the Text Entry Tool and create heartbeat header text to signal the
beginning of the heartbeat message. Characters from NUL (00H) to ~ (7EH) can be
used. Click Submit to save your text to the origin window text field, or click Cancel to
return to origin window without transferring text.
The Heartbeat Message (header) string must be different from the Heartbeat
Terminator string.
Heartbeat
Terminator
(max. 32
chars)
Click to activate the Text Entry Tool and create Heartbeat Terminator text to
signal the end of the heartbeat message. Characters from NUL (00H) to ~ (7EH) can
be used. Click Submit to save your text to the origin window text field, or click Cancel
to return to origin window without transferring text.
The Heartbeat Terminator string must be different from the Heartbeat Message
(header) string.
