BARCODE SCANNING FEATURES
NETCONFIG
Once entered from a Master scanner in a multi-scanner array (tunnel), the system detects
and identifies Slave scanners in the array. The Slave scanners (and the Master) will then be
available in e-Genius (see chapter 4).
Press the X-Press button once again to exit.
5.5.2 Restore Button and Other Functions
Hold down RESTORE button until all LEDs turn on. After all LEDs go off,
then READY LED comes back on. Parameters stored in the CBX510 are
now being used in the scanner.
Hold down X-Press button while scanner is powered up.
Reset Scanner to
Factory Defaults
Hold down X-Press and RESTORE buttons while scanner powers. When
default is successful, all LEDs will flash 3 times.
To Next Page
