4.6.2 Device Settings | Device Name | Mounting
Use the Mounting window to configure some aspects of the scanner LEDs and X-Press
interface.
To view and edit the Mounting settings:
1. In the tree menu under Modify Settings, navigate to Device Settings | Device Name (if
applicable) | Mounting. The Mounting window opens.
NOTE: If more than one device is included in the scanning system, the
device name will be listed in the menu tree after the Device Settings
level.
2. Enter the appropriate information in the form as described below:
Select Specify Mounting or PackTrack Calibration from the drop-down list. If
Specify Mounting is selected, you must manually enter the requested data. If
PackTrack Calibration is selected, use the wizard to automatically enter most of
the data.
NOTE: At the release of this manual, PackTrack Calibration
is the only available option.
