3.11 PHOTOELECTRIC SENSOR CONNECTIONS TO CBX510
Barcode scanning applications may use a Datalogic photoelectric sensor as a trigger device.
The photoelectric sensor is wired directly into the CBX510 terminal.
If your application uses a trigger other than the one specified by Datalogic, follow the
appropriate wiring diagram to assure proper wiring.
NOTE: To confirm the photoelectric sensor is functioning properly, watch
the TRIG LED while the photoelectric sensor’s beam is blocked. The
Datalogic photoelectric sensor also includes a status LED.
The following diagrams illustrate standard recommended wiring of the Photoelectric Sensor
to the CBX510 terminal block.
