Datalogic DS8110 User Manual

INTRODUCTION
11
1
1.10 SC5000 SYSTEM CONTROLLER
The SC5000 Controller offers all the necessary functions to make the phases of installation,
setup, testing, and maintenance of the omni-directional reading array or tunnel easy and
quick.
The SC5000 Controller is fully compatible with DS8110 and DX8210 scanners and its sturdy
mechanical structure makes the SC5000 Controller the ideal solution for industrial
environments. The Controller allows connection to the Trigger and Encoder/Tachometer.
PNP inputs are available via M12 circular connectors, placed on the lower front panel (see
section 3.12).
Figure 12: SC5000 System Controller
System Controller
SC5000-1000 System Controller
Standard
935750001
SC5000-1100 System Controller
Profibus
935750002
SC5000-1200 System Controller
Profinet
935750003

Datalogic DS8110 Specifications

General

Brand	Datalogic
Model	DS8110
Category	Barcode Reader
Language	English
