1.9 CBX INDUSTRIAL CONNECTION BOX
CBX Series are industrial connection boxes that can be used to connect the barcode
scanners to an encoder/tachometer, photoelectric sensor, serial devices, relays, or other
peripherals. The CBX510 includes a BM100 backup module, which allows easy parameter
restore and backup operations. The backup module also provides an easy way to upload
existing parameters to a replacement barcode scanner when necessary. See section 3.9.1
for wiring options.
Figure 11: CBX510 Connection Box
