Datalogic DS8110 User Manual

TECHNICAL FEATURES
261
8
8 TECHNICAL FEATURES
This chapter provides detailed specifications for the DX8210 Omnidirectional Barcode
Scanning Systems. It provides specific information on:
 Electrical Features
 Optical Features
 Reading Features
 Physical Features
 Environmental Features
 X-PRESS Interface
 Software Features
8.1 TECHNICAL SPECIFICATIONS
ELECTRICAL FEATURES
Power
Supply Voltage
20-30VDC
Consumption
0.72 to 0.5 A Max. (1.3 A max peak at motor start-up)
20 W typical
Distributable Current
(through I/O connector)
0.6 A Max.
Communication Interfaces
Main RS232
Main RS422 full-duplex
1200 to 115200 bit/s
1200 to 115200 bit/s
Auxiliary RS232
1200 to 115200 bit/s
Ethernet (x2) TCP/IP
100 Mbit/s
EBC Internal Network
100 Mbit/s
Fieldbus
Embedded: EtherNet/IP
Supported through CBX510 connection box or SC5000 models:
PROFINET-IO, PROFIBUS-DP
Inputs
3 opto-coupled and polarity insensitive NPN/PNP digital inputs (5-30
Vdc)
Outputs
2 opto-coupled software programmable NPN digital outputs
OPTICAL FEATURES
Wavelength
630 to 680 nm
Safety Class
Class 2 - EN60825-1; Class II – CDRH
Light Source
Visible laser diode
Laser Control
Security system to turn laser off in case of motor slow down
Optic Architecture /
Technology
ASTRA™
Focusing System
Fixed focus position
