DS8110 REFERENCE MANUAL

4.5.3 Modify Settings | Global Settings | Barcode Configuration

Use Barcode Configuration to configure how the system defines a no read barcode, and

configure and filter NOREAD messages.

To edit the Barcode Configuration:

1. In the tree menu under Modify Settings, navigate to Global Settings | Barcode

Configuration. The Barcode Configuration window opens.

2. Enter the appropriate information in the form as described below:

Field Name

Action/Definition

Code

Combination

Select Single Label, Standard Multi Label, Logical Combination, or Code

Collection from the drop-down list. The Code Combination parameter selects the

decoding mode for the scanner.

 Single Label: In this mode only one barcode can be read in each reading

phase; however it can be determined automatically from up to 10 enabled

codes. The scanner stops decoding as soon as a code is read.

If the code is not read during the reading phase, the No Read message is

produced.

 Standard Multi Label: In Multi Label mode the barcodes selected (up to 10),

will all be read in the same reading phase. If the reading phase terminates

before all the codes are read, a Global No Read message will be produced,

unless it is disabled, in which case a Local No Read will be produced.

NOTE: In case of Multi Label, the codes will be

distinguished EITHER by their symbology, OR by their

contents. If two (or more) codes share the same

symbology and content, the scanner will perceive them as

a unique code.

 Logical Combination: In Logical Combination mode the codes of the groups

defined by the Logical Combination Rule are read in the same reading phase.

 Code Collection: In Code Collection mode expected codes are collected

within a single reading phase in the order in which they are read. The No Read

message is produced only if none of the codes are read. Up to 50 codes can

be collected.
