4.7.1 Diagnostics | Monitor
Use the Diagnostics > Monitor as the primary tool to monitor the reader's operation and bar
code readability in real-time. Status indicators and vital statistics appear on a single screen,
enabling you to effectively and efficiently detect and troubleshoot any problems that may
occur.
To open the Monitor window:
In the tree menu under Diagnostics, navigate to Monitor. The Monitor window opens.
The status indicators in Diagnostics > Monitor indicate the following conditions:
GREEN indicates trigger input. The LED is activated upon trigger input regardless of
trigger source (including software trigger).
GREEN indicates a good (valid) bar code has been decoded.
RED indicates a no-read (or incomplete decode).
