Displays the distance from the laser origin to the scanned barcode.
Displays the position of the code in the scan line.
GREEN indicates the barcode has been scanned by the near-focus laser.
GREEN indicates the barcode has been scanned by the far-focus laser.
Displays message data being returned by the scanner for each barcode scanned.
Displays the number of packages detected since the last reset.
Displays the number of good barcode reads since the last reset.
Displays the number of multiple barcodes detected since the last reset.
Displays the number of partially read barcodes since the last reset.
Displays the number of no reads (no barcode read on package) since the last reset.
Click to reset the above counters.
Select the option button beside Main, Aux, Socket 1, Socket 2, Socket 3, Socket
4, Socket 5, or Socket 6 to display messages for that host port.
Select the option button beside None to stop displaying messages.
Click Disconnect to stop (freeze) the Monitor window, or click Connect to start the
Monitor window.
