5.8 TYPICAL LAYOUTS
The following typical layouts refer to system hardware configurations, but also require the
correct setup of the software configuration parameters
Other layouts require the use of a specific SC5000 Controller model.
The accessories and cables indicated in the following figures are Datalogic products. We
suggest their use to guarantee the correct system functioning.
5.8.1 Large Synchronized Network Layout
When building a large local EBC (Ethernet Based Connectivity) network an SC5000
Controller should be used together with a PWR-480B power supply unit. In this case the
SC5000 unit acts as the system master and is connected to the host through one of its
interfaces.
The SC5000 can be connected to the Host in several different layouts depending on the
controller model.
The SC5000 Standard models provide both Ethernet connections (direct or through a
Hub/Switch) and point-to-point connections on the Main interface using either RS232 or
RS422 full-duplex;
Fieldbus models, additionally provide the model specific Fieldbus: Profibus, Profinet IO,
etc.
All scanners act as slaves and are connected to the SC5000 through the EBC interface.
External devices such as a presence sensor and an encoder are all connected either to the
SC5000 through its M12 circular connectors, or to the CBX510 connection box (connected to
the Controller), wiring the signals through the CBX510 compression connectors.
