Datalogic DS8110 User Manual

DS8110 REFERENCE MANUAL
186
4
4. The graphic on screen indicates Extract Image is in-process. A message will appear
when Extract Image is complete.
0.
To Burn Flash:
1. Click Choose File. In the browse window, select an image file (*.as) to burn to flash.
NOTE: The appearance of these functions may vary from
browser to browser.
2. Click Burn Flash. The graphic on-screen indicates Burn Flash is in-process.
3. A message will appear when Burn Flash is complete.
0.
To Reboot the System:
1. Click Reboot. A confirmation box appears.
2. Click OK to reboot the system, or click Cancel to return to the reboot window without
restarting the system.
0.

Datalogic DS8110 Specifications

General

Brand	Datalogic
Model	DS8110
Category	Barcode Reader
Language	English
