For Advanced Data Format only, by enabling this parameter all multiple
read labels will be included in the output message. They can be separated by
the Multiple Read Separator.
Multiple Read Label Separator String (max. 128 chars):
The Multiple Read Label Separators (up to 128 bytes) are used to
separate multiple read barcodes in the reading phase.
This is meaningful when the Code Combination parameter is set to Multi
Label or Logical Combination and the Send All Multiple Read Labels
parameter has been enabled.
If selected, they occur within the Code Field and are transmitted after each
decoded multiple read barcode.
Select the check box to reveal the Max Number of Different Characters
field.
When checked, this filter attempts to eliminate false multiple reads by
determining if a short code read is "contained in" (is a sub-string of), another
longer code read. This condition implicates that the short code is probably a
misread of the same longer code and therefore should be ignored, (should
not be considered as a multiple read of a different code).
This filter is based upon the following rules:
a multiple read condition occurs
all decoded codes of the same type are compared with each other
Rule 1: the shorter code is considered contained in the longer code if the
character string is found in the same order; the longer code may have a
single block of characters in any position (before, after or in between the
compared strings)
Example: The code 123456 is considered contained in the following
codes: 00123456, 12345600, 12378456.
The code 123456 is not considered contained in the following codes:
12346507 (string out of order), 12345700 (string not complete),
120378456 or 0012345600 (multiple blocks in the string).
