OUTPUTS
PRODUCT REFERENCE GUIDE
91
Output 3 Connections Using Matrix 220 Power (CBX500 Only)
Power to Out-
put Device
Output Device
Reference
Output
Signal
Output 3 Device
Figure 69 - Output 3 Using Matrix 220 Power
Output 3 Connections Using External Power (CBX500 Only)
Output Device
Reference
Output
Signal
Output 3 Device
Figure 70 - Output 3 Using External Power
CAUTION
Do not connect to I3A or I34B signals, they are reserved.
