PRODUCT REFERENCE GUIDE
69
CHAPTER 4
ELECTRICAL CONNECTIONS
All Matrix 220 Standard Input Power models can be connected to a CBX connection box
through one of the available CAB-DSxx-S accessory cables. These accessory cables ter-
minate in an M12 17-pin connector on the Matrix 220 side and in a 25-pin male D-sub
connect
or on the CBX side.
NOTE
We recommend making system connections through one of the CBX connection boxes
since they offer the advantages of easy connection, easy device replacement, opto-iso-
lated outputs (Outputs 1 and 2), and filtered reference signals.
NOTE
All Matrix 220 Power over Ethernet (PoE) models have an additional
COM and Trigger connector which can be connected through custom
cables. See
Appendix A for direct wiring details.
If you require direct wiring to the reader the connections are the same
as shown in this chapter with the exception of the digital Outputs. Direct
wiring details are indicated in
Appendix A.
