Datalogic Matrix 220 User Manual

Power
Standard Models PoE Models
Supply Voltage 10 to 30 Vdc 48 Vdc
Consumption 0.40 - 0.14 A (4.2 W) max 0.10 A (4.8 W) max
Communication Interfaces
Main: RS232, RS422 Full-duplex 2400 to 115200 bit/s
Auxiliary: RS232 2400 to 115200 bit/s
ID-NET Up to 1 Mbaud
Ethernet (Built-in)
supported application protocols
10/100 Mbit/s
TCP/IP, UDP, FTP, EtherNet/IP, Modbus TCP, PROF-
INET-IO, OPC UA
Inputs
Input 1(External Trigger) and Input 2
Opto-coupled and polarity insensitive
Max. Voltage 30 Vdc
Max. Input Current 10 mA
Outputs
a
a. when connected to the CBX connection boxes the electrical features for Output 1 and 2 become
the following:
Opto-isolated; V
CE
= 30 Vdc max.; I
CE
= 40 mA continuous max.; 130 mA pulsed max.;
V
CE saturation
= 1 Vdc max. @ 10 mA; P
D
= 90 mW Max. @ 50 °C ambient temp.
Output 1, 2 and 3
NPN or PNP short circuit protected;
V
OUT
(I
LOAD
= 0 mA) Max.
30 Vdc
V
OUT
(I
LOAD
= 100 mA) Max.
3 Vdc
I
LOAD
Max.
100 mA
180 MATRIX 220
APPENDIX A
TECHNICAL FEATURES
ELECTRICAL FEATURES
