RAPID CONFIGURATION
26 MATRIX 220
STEP 7 - TEST MODE
Use a code suitable to your application to test the reading performance of the system.
1. Enter the Test
function by pressing and holding the X-PRESS push button until the
Test LED is on.
2. Release the button to enter the Te
st
function.
Once entered, the Bar Graph on the five LEDs is activated and if the reader starts
reading
codes the Bar-Graph shows the Good Read Rate.
3. To exit the Test, press the X-PRESS push button once.
NOTE
The Bar Graph has the following meaning:
≥ 20% ≥ 40% ≥ 60% ≥ 75% ≥ 95%
In case of No Read condition, only the STATUS LED (red) is on and blinks.
By default, the Test exits automatically after three minutes.
