NOTE

STEP 4 - X-PRESS CONFIGURATION

PRODUCT REFERENCE GUIDE

Reset Reader to Factory Default Environment (Optional)

If it ever becomes necessary to reset the reader’s Environment parameters to their fac-

tory default values, you can perform this procedure by holding the X-PRESS push button

pressed while powering u

p the reader. You must keep the X-PRESS push button pressed

until all LEDs blink simultaneously for about 3 seconds. Release and re-press the but-

ton during this LED blinking sequence.

All the device’s Environment parameters are reset includi

ng the default IP Address. The

Matrix 220 emits 3 high pitched beeps and after a few seconds enters run mode.

Any previously saved configurations on the device will remain in memory

, but the

Default configuration is set as the startup configuration.

NOTE

The Grade A Barcode Test Chart cannot be used to set the Code 128 sym-

bology (even though the reader successfully reads the code). Use the

application specific code if you need to set this symbology.

When using X-PRESS or the BM150 menu to perform Auto-Learn, only a

single code

can be configured (successive Learns will substitute the

current code). To configure multiple codes, use the DL.CODE Auto-Learn

procedure.

You can always exit from any X-PRESS function at any time by pressing

the X-PRESS push button once. After a short delay the procedure is can-

celled.

If you have used this procedure to configure Matrix 220, go to step 7.

If you release the button while the LEDs are all on continuously (after

the blinking phase), the reader will enter the Loader program sequence

and the LEDs will begin to cycle through various patterns. Just cycle

power to return to run mode.

Datalogic Matrix 220 User Manual
