MATRIX 220
CHAPTER 3
INSTALLATION
PACKAGE CONTENTS
Verify that the Matrix 220 reader and all the parts supplied with the equipment are
present and intact when opening the packaging; the list of parts includes:
• Matrix 220 reader (w/connector plug/cover)
• Quick Reference Guide
•Test Chart
• Mounting Kit
• Mounting Screws (2)
•Washers (2)
• Mounting Bracket
Figure 30 - Package Contents
For Ethernet models the sealing connector plug provides IP67 protection when Ethernet
is not used. For PoE models the COM/Trigger connector cover provides this protection
when not used.
