READING DIAGRAMS
PRODUCT REFERENCE GUIDE 115
Matrix 220 (7 mm models) 2D Codes
Matrix 220 (7 mm lens - 38° Horizontal View Angle)
Data Matrix 0.13 mm (5 mils)
Reading Distance
Horizontal FoV
0.5
1.0
1.5
2.0
-2.0
-1.5
-1.0
-0.5
2.0 2.5 3.0 3.5 4.0
0
inch
mm
4.5
Conditions
Hardware Settings
Code Symbology Data Matrix ECC 200
Code Resolution 5 mils
Tilt Angle 0°
Skew Angle 15°
Focusing Distance 95 mm
Software Parameters
Reader Model
STD
(352-xxx)
DPM-R
(382-xxx)
DPM-B
(392-xxx)
DPM-R-HP
(302-xxx)
Sectors | LED
Group
To
p + Bottom Diffused Diffused Polarized
Exposure Time 80 μs 280 μs 300 μs 220 μs
Gain 8 28 30 20
Gain Multiplier x1 x2 x2 x1
