STEP 2 - MOUNT AND POSITION THE READER
PRODUCT REFERENCE GUIDE
3
STEP 2 - MOUNT AND POSITION THE READER
1. To mount the Matrix 220, use the mounting brackets to obtain the most suitable
position for the reader. The most common mounting configuration is shown in the
figure below.
Figure 7 - Positioning with Mounting Bracket
2. When mounting the Matrix 220 take into consideration these three ideal label
position angles: Pitch or Skew 10° to 20° and Tilt 0°, although the reader can read
a code at any tilt angle provided the code fits into the Field Of View (FOV).
