RAPID CONFIGURATION
8 MATRIX 220
STEP 5 - INSTALLING DL.CODE CONFIGURATION PROGRAM
DL.CODE is a Datalogic reader configuration tool providing several important advan-
tages:
• Intuitive Graphical User Interface for rapid configuration
• Defined configuration directly stored in the reader
• Discovery and IP address setting features to facilitate remote configuration
• Device Monitoring
To install DL.CODE
1. On the PC that will be used for configuration, (running Windows 7, 8.1, or 10), down-
load the DL.CODE mini-DVD.zip file. Extract the files maintaining the folder structure
and run the st
art.hta file to access the installation pop-up. Click on the Install
DL.CODE link to run the installation program and follow the installation procedure.
NOTE
2. When the installation is complete the DL.CODE entry is created in the Start>Pro-
grams bar under “Datalogic” as well as a desktop icon. Double-click the desktop
icon to
run it.
This configuration procedure assumes a laptop computer, running DL.CODE, is con-
nected to a factory default reader through the Ethernet port.
CAUTION
DL.CODE does not currently support Windows Embedded (often used in
industrial PCs and/or PLCs).
To perform a “silent” installation (without user input), see the DL.CODE
User’s Guide.
