READING FEATURES
116
MATRIX 220
Matrix 220 (12 mm models) 1D Codes
Matrix 220 (12 mm lens - 24° Horizontal View Angle)
Code 128 0.15 mm (6 mils)
Reading Distance
Horizontal FoV
1
2
3
-3
-2
-1
8 9 10 11 12 13
0
inch
mm
Conditions
Hardware Settings
Code Symbology Code 128
Code Resolution 6 mils
Tilt Angle 0°
Skew Angle 15°
Focusing Distance 300 mm
Software Parameters
Reader Model DPM-R (385-xxx) DPM-B (395-xxx) DPM-R-HP (305-xxx)
LED Group Non Polarized Non Polarized Non Polarized
Exposure Time 400 μs 450 μs 260 μs
Gain 46 50 26
Gain Multiplier x2 x2 x2
