Datalogic Matrix 220 User Manual

READING FEATURES
118 MATRIX 220
Matrix 220 (12 mm models) 2D Codes
Matrix 220 (12 mm lens - 24° Horizontal View Angle)
Data Matrix 0.076 mm (3 mils)
Reading Distance
Horizontal FoV
0.25
0.50
0.75
1.00
-1.00
-0.75
-0.50
-0.25
3.00 3.50 4.003.75 4.25
0
inch
mm
3.25
Conditions
Hardware Settings
Code Symbol-
ogy
Data Matrix ECC 200
Code Resolu-
tion
3 mils
Tilt Angle 0°
Skew Angle 15°
Focusing Dis-
tance
102 mm
Software Parameters
Reader Model
STD
(355-xxx)
STD-W-HP
(345-xxx)
DPM-R
(385-xxx)
DPM-B
(395-xxx)
DPM-R-HP
(305-xxx)
Sectors | LED
Gr
oup
Top
+ Bottom
Internal +
External
Diffused Diffused Polarized
Exposure Time 120 μs 70 μs 350 μs 400 μs 280 μs
Gain 12 10 40 40 28
Gain Multiplier x1 x1 x2 x2 x1
