ELECTRICAL CONNECTIONS
70 MATRIX 220
CBX CONNECTION BOX PINOUT
The table below gives the pinout of the CBX100/500 terminal block connectors. Use this
pinout when the Matrix 220 reader is connected by means of the CBX100/500:
Group Label Description
Input
Power
Vdc Power Supply Input Voltage +
GND Power Supply Input Voltage -
Earth Protection Earth Ground
Inputs +V Power Source - External Trigger
I1A External Trigger A (polarity insensitive)
I1B External Trigger B (polarity insensitive)
-V Power Reference - External Trigger
Inputs +V Power Source - Inputs
I2A Input 2 A (polarity insensitive)
I2B Input 2 B (polarity insensitive)
-V Power Reference - Inputs
Outputs +V Power Source - Outputs
-V Power Reference - Outputs
O1+ Output 1 + opto-isolated and polarity sensitive
O1- Output 1 - opto-isolated and polarity sensitive
O2+ Output 2 + opto-isolated and polarity sensitive
O2- Output 2 - opto-isolated and polarity sensitive
O3A Output 3 - non opto-isolated (only available through CBX500)
Auxiliary
Interface
TX Transmit Data
RX Receive Data
SGND Auxiliary Interface Signal Ground
ID-NET REF Network Reference
ID+ ID-NET network data +
ID- ID-NET network data -
Shield Network Cable Shield
Main
Interface
RS232 RS422 Full Duplex
TX TX+
RX *RX+
- TX-
- *RX-
SGND SGND
* Do not leave floating, see "RS422 Full Duplex Interface" on page 74 for connection details.
