Datalogic Matrix 220

TYPICAL LAYOUTS
98 MATRIX 220
When using a Local Area Network (LAN), one or more Matrix 220 readers can be con-
nected to the network by using CAB-ETH-X-M0x cabl
es:
Host
CAB-DSxx-S
Matrix 220
CAB-ETH-X-M0x



Ethernet Interface
Auxiliary Serial Interface (RS232 - Data Monitor)
External Trigger (for One Shot or Phase Mode)
Alone



Alone Alone
CBX
CBX
Switch
Power
Figure 75 - Ethernet Network Layout
Host
Matrix 220
CAB-ETH-X-M0x
Alone Alone Alone
PoE Switch
Figure 76 - PoE Ethernet Network Layout
