Datalogic Matrix 220 User Manual







 

Standard Model PoE Model
GENERAL VIEW
xiv MATRIX 220
Figure 2 - General View of Standard Models
1. Reading Window 7. X-PRESS Interface
2. Mounting Holes (2) 8. Ethernet Connector
3. Power On LED 9. Power, COM, I/O Connector
4. Ethernet Connection LED 10. Power Over Ethernet Connector
5. 90° Rotating Connector Block 11. COM, T
rigger Connector
6. Accessory Windo
w Cover

Datalogic Matrix 220 Specifications

General

Brand	Datalogic
Model	Matrix 220
Category	Barcode Reader
Language	English
