Datalogic Matrix 220

NOTE
RAPID CONFIGURATION
18 MATRIX 220
7. Now select the General Image Settings branch and click on the Focus Autolearn
button.
The Reading Distance value is
not significant until the Focus
Autolearn procedure ends
successfully.
8. The Calibrate dialog box opens allowing you to start the procedure. Click Start.
For applications having multiple lighting or code reading conditions, up
to 10 different Image Settings can be configured by adding them with the
icon.
