Figure 88. Installing the memory module
Steps
1. Align the notch and slide the memory module until it clicks into place.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
NOTE: Repeat step 1 and step 2 for rest of memory module slots (if applicable).
Next steps
1. Install the air shroud.
2. Install the side cover.
3. Follow the procedure in after working inside your computer.
Bottom air shroud
Removing the bottom air shroud
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the air shroud.
About this task
The following images indicate the location of the bottom air shroud and provide a visual representation of the removal
procedure.
