Dell Precision 7875 Tower - Installing the Lockable Front Bezel for the Hard Drive

Steps
1. Insert the key into the keyhole.
2. Rotate the key 90 degrees clockwise to unlock the bezel.
3. Remove the key from the bezel.
Note: Perform step 1 to step 3, to remove second lockable front bezel for the hard drive (if applicable).
Installing the lockable front bezel for the hard drive
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the lockable front bezel for the hard drive and provide a visual representation of
the installation procedure.
Figure 21. Installing the lockable front bezel for the hard drive
Steps
1. Position the front bezel to align the tab on the bezel with the slot on the chassis.
2. Insert the key into the keyhole.
