Serial card
Installing the serial card
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the serial card and provide a visual representation of the installation procedure.
NOTE: Precision 7875 Tower supports only two serial cards in slots 6, 5, 4, 3, or 1.
Figure 67. Installing the serial card
Steps
1. Push down the PCIe latch to open the PCIe door.
2. Slide and lift the PCIe filler from the PCIe slot.
3. Align and place the serial card into the expansion slot.
Removing and installing Customer Replaceable Units (CRUs)
93
