Figure 53. Installing the 2.5-inch hard-drive assembly
Steps
Slide and insert the 2.5-inch hard-drive assembly into the slot on the hard-drive bracket.
NOTE:
Push the hard-drive assembly into the slot until it clicks into place, which indicates that the assembly is locked into
position.
Next steps
1. Install the side cover.
2. Follow the procedure in After working inside your computer.
Expansion card
UltraSpeed Duo
Installing the UltraSpeed Duo card
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the UltraSpeed Duo card and provide a visual representation of the installation
procedure.
NOTE: Precision 7875 Tower supports only one UltraSpeed Duo card in slot 6, 5, or 4.
Removing and installing Customer Replaceable Units (CRUs) 79
