Figure 49. Installing the 3.5-inch hard-drive assembly
Steps
Slide and insert the 3.5-inch hard-drive assembly into the slot on the hard-drive bracket.
NOTE:
Push the hard-drive assembly into the slot until it clicks into place, which indicates that the assembly is locked into
position.
Next steps
1. Install the side cover.
2. Follow the procedure in After working inside your computer.
2.5-inch hard-drive assembly
Removing the 2.5-inch hard-drive assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
About this task
The following images indicate the location of the 2.5-inch hard-drive assembly and provide a visual representation of the
removal procedure.
Removing and installing Customer Replaceable Units (CRUs)
75
