Dell Precision 7875 Tower - Installing the External 3.5-Inch Hard-Drive Assembly

Figure 28. Installing a 3.5-inch hard drive from the external hard-drive assembly
Steps
1. Place the hard drive into the external hard-drive bracket to align the pins on the bracket with the slots on the hard drive, and
snap the hard drive into the external hard-drive bracket.
2. Snap the hard drive into the external hard-drive bracket.
NOTE:
Perform step 1 to step 2 to install the second external 3.5-inch hard-drive assembly from the lower bay (if
applicable).
Next steps
1. Install the external 3.5-inch hard-drive assembly.
2. Follow the procedure in After working inside your computer.
Installing the external 3.5-inch hard-drive assembly
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the external 3.5-inch hard-drive assembly and provide a visual representation of
the installation procedure.
NOTE: Precision 7875 Tower can support two external 3.5-inch hard-drive assemblies.
54 Removing and installing Customer Replaceable Units (CRUs)
