Steps
1. Push the PCIe latch down and open the PCIe door.
2. Lift and remove the serial card away from the expansion-card slot.
3. Slide the PCIe door down and push the PCIe latch to close the PCIe door.
Graphics card
Installing the non-powered graphic card
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the non-powered graphic card and provide a visual representation of the
installation procedure.
NOTE: Precision 7875 Tower supports only two graphic cards in slots 2 and 5.
NOTE: NVIDIA GeForce RTX 4090 can only be installed in slot 2 due to installation limitations.
Removing and installing Customer Replaceable Units (CRUs) 95
