16. Front bezel
17. Front I/O bracket
18. Slim optical-drive
19. Chassis
20. System board
21. Internal hard drive cage
22. Processor
23. External solid state drive cage
24. External storage flex bay (solid state drive)
25. External storage flex bay (hard drive)
26. Rear-fan assembly
27. Air shroud
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
