3. Align and place the 10G network adapter into the expansion slot.
4. Lift the PCIe latch to close the PCIe door.
5. Route the 10G network adapter cable through the routing guides on the chassis.
6. Connect the 10G network adapter cable to the connector on the system board.
Next steps
1. Install the side cover.
2. Follow the procedure in After working inside your computer.
Removing the 10G network adapter
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
About this task
The following images indicate the location of the 10G network adapter and provide a visual representation of the removal
procedure.
NOTE: Precision 7875 Tower supports only one 10G network adapter in slots 6, 5, 4, or 1.
Removing and installing Customer Replaceable Units (CRUs) 99
