MAINTENANCE & FAULT FINDING
Print head carrier Printer front (left side)
(1) Ribbon Alarm
ancer arm will activate the Ribbon Alarm sensor. A failing
The Ribbon Warning sensor is used to measure the amount of unused ribbon.
X is
(3) Home sensor
If this sensor fails, the printer cannot locate the home position for the print head carrier
and reports Error 1.
3
1
2
If the ribbon breaks, a d
sensor results in a ribbon break not being detected immediately.
(2) Ribbon Warning
If this sensor fails, a ribbon error will be presented for every X prints, where
determined by the actual message printed. Usually 2-6 prints.
(
214) 27864 Issue 1 January 2008
