INSTALLATION
V400 - Optional Manual Bracket
Manual Bracket System
Bracket parts.
1. Mounting plate for the V400 printer
2. Packaging machine large mounting angle
3. Packaging machine small mounting angle
The Manual Bracket System ensures a safe mounting of the printer on the packaging
ma ne, a akes to set up and adjust the printer according to requirements.
Bracket Sy
Type: VASHBTM100X (where X determines the width)
chi nd m
stem for V400:
it easy
X Min. Max.
Width Width Width
4 750
mm
610 mm
5 490 mm 630
mm
6 730 mm 870
mm
(
28) 27864 Issue 1 January 2008
