INSTALLATION
V400 - Optional Automatic Bracket
4 Issue 1January 2008 (29)
Automatic Bracket System
The automatic bracket system allows the V400 printer to print over a larger area
ary)
r to drive the vertical movement and is controlled via
roller and
ing machine.
The automatic bracket comprises of unguarded moving parts and must be installed to
ensure a safe operating environment.
The automatic bracket is supplied with installation guidelines and an operations
manual.
during each printing cycle (whilst the material to be printed remains station
The automatic bracket moves the printer vertically in steps after each horizontal stroke
of the printer.
The bracket uses a stepper moto
a dedicated control module which uses signals from the V Series cont
packag
V400 Printer
Automatic
Bracket
2786
