INSTALLATION
I/O Settings
4 Issue 1January 2008 (51)
This menu display is as follows:
es 1 cycle,
waits for a new start signal. Open and close the start contact again for a new
Level – triggered: After the start contact has been closed, the printer prints
ignal has been removed, and will then stop at the end of a print
• Continuous: Used for test purposes. Internal start signal whose interval is
label length.
(2) RS while print
Defines whether the system should report back ready (or not ready) while printing.
(3) RS while returning
(V100 and V400 printers)
1
2
I/O Settings (All printers)
(1) Start signal
The signal can be set-up in three ways
• Front edge: After the start contact has been closed the printer mak
and
print cycle.
•
until the start s
cycle.
defined by the actual
I/O Settings (V200 printers)
4
3
I/O Settings (V100 & V400 printers)
2786
