INSTALLATION
I/O Test
46) 27864 Issue 1 January 2008
(1) Input
lumn shows the status of the four inputs to the system. Possible values are
(2) Output
(3) Loop test
The loop test requires the use of a special cable (loop cable) that will test the unit’s
input/output signals.
The input co
open or closed.
Use the buttons to force the output to either open or closed (simply press the output
you wish to change).
3
1
2
(
