User’s Manual
106
Users can setup at most 8 monitoring areas. Click on <Clear All> button to
delete all boxes. Alternatively, right click on any single box to delete it
individually.
Sensitivity: Setup a desired sensitivity level.
Interval: The time specified here is for determining the lost of objects. If an
object is removed from the selected areas for more than the time specified
here, lost of object alert will be triggered.
Enable Function: Check on it to enable missing/foreign object detection.
Show Region: Check on it to display the detection area visually on the
monitoring screen. The boxes will also be captured and displayed on the
snapshot images.
Clear All: Click on it to clear all selected boxes.
Apply: Click on it to save and apply settings in the configuration section.
Start Simulation: Click on it to start simulating object detection. As shown in
the previous page, green boxes will mark the lost of objects.
Stop Simulation: Click on it to stop simulation.
Live: Click on it to restore the Video Preview frame to live image.
Lost of Object Alerts
When lost of object alerts are detected, restore the object detected search
window and the list on the left-hand side will show area number and time of
the lost of object alerts.
If the connected site is a DVR, double click on any item to playback video that
is 15 seconds before the alert triggered. However, if the video is not added to
the database yet, an error message will be displayed.
NOTE: Only the configuration of area positions, sensitivity, and interval
will be permanently saved. The default image will be replaced by the
initial image every time when CMS restarts. Therefore, please check
the configuration every time CMS starts up.
