3 Installation
3.5 Power plug
Rapid Link 5 · RAMO5 · RASP5 05/20 MN034004EN www.eaton.com 101
3.5.2 RASP5
Two types of power plugs are available.
RA-C3… (for RASP5…512…)
Table 19: Pin assignment of the RA-C3… power plug of type HANQ5/0
Figure 61: Energy connector RA-C3…
Pin
Function Power plug
1 L1
2 L2
3 L3
4
N
5
–
PE PE
DANGER
5 MIN
4
5
3
12
e
